標稱截面
|
結構，根數(shù)/單徑
(mm)
|
外徑
(mm)
|
標稱截面
鋁/鋼
|
結構,根數(shù)/單徑
(mm)
|
外徑
(mm)
|
鋁 |
鋼 |
16 |
7/1.7 |
5.10 |
10/2 |
6/1.50 |
1/1.50 |
4.50 |
25 |
7/2.15 |
6.45 |
16/3 |
6/1.85 |
1/1.85 |
5.55 |
35 |
7/2.50 |
7.50 |
25/4 |
6/2.32 |
1/2.32 |
6.96 |
50 |
7/3.00 |
9.00 |
35/6 |
6/2.72 |
1/2.72 |
8.16 |
70 |
7/3.60 |
10.80 |
50/8 |
6/3.20 |
1/3.20 |
9.60 |
95 |
7/4.16 |
12.48 |
50/30 |
12/2.32 |
7/2.32 |
11.60 |
120 |
19/2.85 |
14.25 |
70/10 |
6/3.80 |
1/3.80 |
11.40 |
150 |
19/3.15 |
15.75 |
70/40 |
12/2.72 |
7/2.72 |
13.60 |
185 |
19/3.50 |
17.5 |
95/15 |
26/2.15 |
7/1.67 |
13.61 |
210 |
19/3.75 |
18.75 |
95/20 |
7/4.16 |
7/1.85 |
13.87 |
240 |
37/4.00 |
20.00 |
95/55 |
12/3.20 |
7/3.20 |
16.00 |
300 |
37/3.20 |
22.40 |
|
|
|
|
400 |
37/3.70 |
25.90 |
|
|
|
|
500 |
61/4.16 |
29.12 |
|
|
|
|
630 |
61/3.63 |
32.67 |
|
